Ten backup combinations that really help when the network goes down

11.05.2020


Most resurces in our households fail to work without electricity. LG Chem describes which combinations of RESU battery systems with different inverters you should choose to be safe when the grid is offline.


Please click the link below to view the article:

https://lghomebatteryblog.eu/en/eleven-backup-combinations-that-really-help-when-the-network-goes-down/


RESU Prime

RESU10H Prime

Specification
  • Usable Energy (kWh)

    9.6

  • Weight (kg)

    111

  • Dimensions (mm)

    504 x 817 x 295

  • Communication Interface

    CAN & RS485

  • Enclosure Protection Rating

    IP55

Energy Pack/Rack

TR1300

Specification
  • Energy (kWh)

    327.712

  • Capacity (Ah)

    290

  • Nominal Voltage (V)

    1,130.36

  • Voltage Range (V)

    924 – 1,293.6

  • Dimension (W x H x D, mm)

    1040 x 1200 x 1745

  • Weight (kg)

    2308

RESU Gen2 Modular

RESU10M

Specification
  • Total Energy (kWh)

    9.8

  • Usable Energy (kWh)

    9.3

  • Weight (kg)

    80.0

  • Dimensions (mm)

    452 x 511 x 240

  • Communication

    CAN 2.0B

  • Enclosure Protection Rating

    IP55

Compatible Inverters

RESU Prime

RESU16H Prime

Specification
  • Usable Energy (kWh)

    16

  • Weight (kg)

    159

  • Dimensions (mm)

    504 x 1,086 x 295

  • Communication Interface

    CAN & RS485

  • Enclosure Protection Rating

    IP55

UPS Pack/Rack

UPS Rack/10 Packs/M4864P6B

Specification
  • Energy (kWh)

    33.0

  • Continuous Power (kW)

    115

  • Nominal Voltage (V)

    515

  • Voltage Range (V)

    420 ~ 588

  • Dimension (W x H x D, mm)

    600 x 2,000 x 650

  • Weight (kg)

    390

UPS Pack/Rack

UPS Rack/12 Packs(6S2P)/M7830P7B

Specification
  • Energy (kWh)

    28

  • Continuous Power (kW)

    250

  • Nominal Voltage (V)

    466

  • Voltage Range (V)

    397 ~ 523

  • Dimension (W x H x D, mm)

    520 x 2,292 x 500

  • Weight (kg)

    480

Stand-alone Pack/Telecom Backup

M48126P3S

Specification
  • Energy (kWh)

    6.5

  • Capacity (Ah)

    126

  • Nominal Voltage (V)

    51.8

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimension (W x H x D, mm)

    445 x 110 x 587

  • Weight (kg)

    44

Stand-alone Pack/Telecom Backup

M4863P3S

Specification
  • Energy (kWh)

    3.3

  • Capacity (Ah)

    63

  • Nominal Voltage (V)

    51.8

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimension (W x H x D, mm)

    445 x 110 x 339

  • Weight (kg)

    24

Power Pack/Rack

R1000 (17 Packs) / M48128P6B

Specification
  • Energy (kWh)

    112.1

  • Capacity (Ah)

    128

  • Nominal Voltage (V)

    876

  • Voltage Range (V)

    714 ~ 1,000

  • Dimension (W x H x D, mm)

    520 x 2,200 x 655

  • Weight (kg)

    924

Power Pack/Rack

R1000 (17 Packs) / M4864P6B

Specification
  • Energy (kWh)

    56

  • Capacity (Ah)

    64

  • Nominal Voltage (V)

    876

  • Voltage Range (V)

    714 ~ 1,000

  • Dimension (W x H x D, mm)

    520 x 2,200 x 425

  • Weight (kg)

    584

Power Pack/Rack

R800 (14 Packs) / M48128P6B

Specification
  • Energy (kWh)

    92.3

  • Capacity (Ah)

    128

  • Nominal Voltage (V)

    721

  • Voltage Range (V)

    588 ~ 823

  • Dimension (W x H x D, mm)

    520 x 1,880 x 655

  • Weight (kg)

    775

Power Pack/Rack

R800 (14 Packs) / M4864P6B

Specification
  • Energy (kWh)

    46.2

  • Capacity (Ah)

    64

  • Nominal Voltage (V)

    721

  • Voltage Range (V)

    588 ~ 823

  • Dimension (W x H x D, mm)

    520 x 1,880 x 425

  • Weight (kg)

    491

Power Pack/Rack

M48128P6B (2P)

Specification
  • Energy (kWh)

    6.6

  • Capacity (Ah)

    128

  • Nominal Voltage (V)

    51.5

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimension (W x H x D, mm)

    445 x 110 x 620

  • Weight (kg)

    47

Power Pack/Rack

M4864P6B (1P)

Specification
  • Energy (kWh)

    3.3

  • Capacity (Ah)

    64

  • Nominal Voltage (V)

    51.5

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimension (W x H x D, mm)

    445 x 110 x 344

  • Weight (kg)

    28

UPS Pack/Rack

UPS Rack/10 Packs/M48128P6B

Specification
  • Energy (kWh)

    65.9

  • Continuous Power (kW)

    132

  • Nominal Voltage (V)

    515

  • Voltage Range (V)

    420 ~ 588

  • Dimension (W x H x D, mm)

    600 x 2,000 x 800

  • Weight (kg)

    625

Energy Pack/Rack

M48145P5B (2P)

Specification
  • Energy (kWh)

    7.4

  • Capacity (Ah)

    145

  • Nominal Voltage (V)

    51.4

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimension (W x H x D, mm)

    445 x 110 x 620

  • Weight (kg)

    46

RESU Gen2 48V

RESU3.3

Specification
  • Total Energy (kWh)

    3.3

  • Usable Energy (kWh)

    2.9

  • Weight (kg)

    31.0

  • Dimensions (mm)

    452 x 403 x 120

  • Communication

    CAN2.0B

  • Enclosure Protection Rating

    IP55

Compatible Inverters

Energy Pack/Rack

M48218P5B (3P)

Specification
  • Energy (kWh)

    11.2

  • Capacity (Ah)

    218

  • Nominal Voltage (V)

    51.4

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimension (W x H x D, mm)

    445 x 110 x 915

  • Weight (kg)

    68

RESU Gen2 48V

RESU6.5

Specification
  • Total Energy (kWh)

    6.5

  • Usable Energy (kWh)

    5.9

  • Weight (kg)

    52

  • Dimensions (mm)

    452 x 656 x 120

  • Communication

    CAN2.0B

  • Enclosure Protection Rating

    IP55

Compatible Inverters

Energy Pack/Rack

M48290P5B (4P)

Specification
  • Energy (kWh)

    14.9

  • Capacity (Ah)

    290

  • Nominal Voltage (V)

    51.4

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimension (W x H x D, mm)

    445 x 110 x 1,162

  • Weight (kg)

    89

Energy Pack/Rack

M48126P3B (2P)

Specification
  • Energy (kWh)

    6.5

  • Capacity (Ah)

    126

  • Nominal Voltage (V)

    51.8

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimension (W x H x D, mm)

    445 x 110 x 620

  • Weight (kg)

    46

RESU Gen2 48V

RESU10

Specification
  • Total Energy (kWh)

    9.8

  • Usable Energy (kWh)

    8.8

  • Weight (kg)

    75

  • Dimensions (mm)

    452 x 484 x 227

  • Communication

    CAN2.0B

  • Enclosure Protection Rating

    IP55

Compatible Inverters

RESU Gen2 48V

RESU13

Specification
  • Total Energy (kWh)

    13.1

  • Usable Energy (kWh)

    12.4

  • Weight (kg)

    99.0

  • Dimensions (mm)

    452 x 626 x 227

  • Communication

    CAN2.0B

  • Enclosure Protection Rating

    IP55

Compatible Inverters

Energy Pack/Rack

M48189P3B (3P)

Specification
  • Energy (kWh)

    9.8

  • Capacity (Ah)

    189

  • Nominal Voltage (V)

    51.8

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimension (W x H x D, mm)

    445 x 110 x 915

  • Weight (kg)

    68

Energy Pack/Rack

M48252P3B (4P)

Specification
  • Energy (kWh)

    13

  • Capacity (Ah)

    252

  • Nominal Voltage (V)

    51.8

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimension (W x H x D, mm)

    445 x 110 x 1,162

  • Weight (kg)

    89

RESU Gen2 400V

RESU7H(Type-R)

Specification
  • Total Energy (kWh)

    7.0

  • Usable Energy (kWh)

    6.6

  • Weight (kg)

    75.0

  • Dimensions (mm)

    744 x 692 x 206

  • Communication

    RS485

  • Enclosure Protection Rating

    IP55

Compatible Inverters

Energy Pack/Rack

R800 (14 Packs) / M48145P5B

Specification
  • Energy (kWh)

    104.3

  • Capacity (Ah)

    145

  • Nominal Voltage (V)

    719

  • Voltage Range (V)

    588 ~ 823

  • Dimension (W x H x D, mm)

    520 x 1,880 x 655

  • Weight (kg)

    760

RESU Gen2 400V

RESU7H(Type-C)

Specification
  • Total Energy (kWh)

    7.0

  • Usable Energy (kWh)

    6.6

  • Weight (kg)

    87.0

  • Dimensions (mm)

    744 x 907 x 206

  • Communication

    CAN2.0B

  • Enclosure Protection Rating

    IP55

Compatible Inverters

RESU Gen2 400V

RESU10H(Type-R)

Specification
  • Total Energy (kWh)

    9.8

  • Usable Energy (kWh)

    9.3

  • Weight (kg)

    97

  • Dimensions (mm)

    744 x 907 x 206

  • Communication

    RS485

  • Enclosure Protection Rating

    IP55

Compatible Inverters

Energy Pack/Rack

R800 (14 Packs) / M48218P5B

Specification
  • Energy (kWh)

    156.4

  • Capacity (Ah)

    218

  • Nominal Voltage (V)

    719

  • Voltage Range (V)

    588 ~ 823

  • Dimension (W x H x D, mm)

    520 x 1,880 x 950

  • Weight (kg)

    1,097

Energy Pack/Rack

R800 (14 Packs) / M48290P5B

Specification
  • Energy (kWh)

    208.5

  • Capacity (Ah)

    290

  • Nominal Voltage (V)

    719

  • Voltage Range (V)

    588 ~ 823

  • Dimension (W x H x D, mm)

    520 x 1,880 x 1,200

  • Weight (kg)

    1,396

RESU Gen2 400V

RESU10H(Type-C)

Specification
  • Total Energy (kWh)

    9.8

  • Usable Energy (kWh)

    9.3

  • Weight (kg)

    99.8

  • Dimensions (mm)

    744 x 907 x 206

  • Communication

    CAN2.0B

  • Enclosure Protection Rating

    IP55

Compatible Inverters

Energy Pack/Rack

R800 (14 Packs) / M48126P3B

Specification
  • Energy (kWh)

    91.3

  • Capacity (Ah)

    126

  • Nominal Voltage (V)

    725

  • Voltage Range (V)

    588 ~ 823

  • Dimension (W x H x D, mm)

    520 x 1,880 x 655

  • Weight (kg)

    766

RESU Gen1

RESU6.4EX Main Pack

Specification
  • Total Energy (kWh)

    6.4

  • Weight (kg)

    60.0

  • Dimensions (mm)

    406 x 664 x 165

  • Communication

    CAN, CAN open

  • Enclosure Protection Rating

    IP21

Energy Pack/Rack

R800 (14 Packs) / M48189P3B

Specification
  • Energy (kWh)

    137

  • Capacity (Ah)

    189

  • Nominal Voltage (V)

    725

  • Voltage Range (V)

    588 ~ 823

  • Dimension (W x H x D, mm)

    520 x 1,880 x 950

  • Weight (kg)

    1,104

RESU Gen1

RESU6.4EX Expansion Pack

Specification
  • Total Energy (kWh)

    3.2

  • Weight (kg)

    30.0

  • Dimensions (mm)

    230 x 664 x 165

  • Communication

    CAN, CAN open

  • Enclosure Protection Rating

    IP21

Energy Pack/Rack

R800 (14 Packs) / M48252P3B

Specification
  • Energy (kWh)

    182.7

  • Capacity (Ah)

    252

  • Nominal Voltage (V)

    725

  • Voltage Range (V)

    588 ~ 823

  • Dimension (W x H x D, mm)

    520 x 1,880 x 1,200

  • Weight (kg)

    1,402

Energy Pack/Rack

R1000 (17 Packs) / M48218P5B

Specification
  • Energy (kWh)

    189.9

  • Capacity (Ah)

    218

  • Nominal Voltage (V)

    873

  • Voltage Range (V)

    714 ~ 1,000

  • Dimension (W x H x D, mm)

    520 x 2,200 x 950

  • Weight (kg)

    1,305

Energy Pack/Rack

R1000 (17 Packs) / M48145P5B

Specification
  • Energy (kWh)

    126.6

  • Capacity (Ah)

    145

  • Nominal Voltage (V)

    873

  • Voltage Range (V)

    714 ~ 1,000

  • Dimension (W x H x D, mm)

    520 x 2,200 x 655

  • Weight (kg)

    905

Energy Pack/Rack

R1000 (17 Packs) / M48290P5B

Specification
  • Energy (kWh)

    253.2

  • Capacity (Ah)

    290

  • Nominal Voltage (V)

    873

  • Voltage Range (V)

    714 ~ 1,000

  • Dimension (W x H x D, mm)

    520 x 2,200 x 1,200

  • Weight (kg)

    1,680

Energy Pack/Rack

R1000 (17 Packs) / M48189P3B

Specification
  • Energy (kWh)

    166.4

  • Capacity (Ah)

    189

  • Nominal Voltage (V)

    881

  • Voltage Range (V)

    714 ~ 1,000

  • Dimension (W x H x D, mm)

    520 x 2,200 x 950

  • Weight (kg)

    1,314

Energy Pack/Rack

R1000 (17 Packs) / M48126P3B

Specification
  • Energy (kWh)

    110.9

  • Capacity (Ah)

    126

  • Nominal Voltage (V)

    881

  • Voltage Range (V)

    714 ~ 1,000

  • Dimension (W x H x D, mm)

    520 x 2,200 x 655

  • Weight (kg)

    912

Energy Pack/Rack

R1000 (17 Packs) / M48252P3B

Specification
  • Energy (kWh)

    221.8

  • Capacity (Ah)

    252

  • Nominal Voltage (V)

    881

  • Voltage Range (V)

    714 ~ 1,000

  • Dimension (W x H x D, mm)

    520 x 2,200 x 1,200

  • Weight (kg)

    1,687

Energy Pack/Rack

R1500 (24 Packs) / M48290P5B

Specification
  • Energy (kWh)

    357.5

  • Capacity (Ah)

    290

  • Nominal Voltage (V)

    1,233

  • Voltage Range (V)

    1,008 ~ 1,411

  • Dimension (W x H x D, mm)

    520 x 3,150 x 1,200

  • Weight (kg)

    2,407
