Product Info
Total 14 Result
RESU FLEX Copy Link
RESU FLEX
Specification- Usable Energy (kWh)
8.6 / 12.9 / 17.2
- Weight (kg)
Battery Protection Unit : 16.6 / Battery Module : 48.9 (without Design Cover, Bracket)
- Dimensions (mm)
665.2 x 665.2 x 148.4 (per module) (without Design Cover, Bracket)
- Communication Interface
RS485, CAN
- Enclosure Protection Rating
IP55
RESU Gen2 Modular Copy Link
RESU10M
Specification- Total Energy (kWh)
9.8
- Usable Energy (kWh)
9.3
- Weight (kg)
80.0
- Dimensions (mm)
452 x 511 x 240
- Communication
CAN 2.0B
- Enclosure Protection Rating
IP55
UPS Backup Solution Copy Link
UPS Rack/10 Packs/M4864P6B
Specification- Energy (kWh)
33.0
- Continuous Power (kW)
115
- Nominal Voltage (V)
515
- Voltage Range (V)
420 ~ 588
- Dimension (W x H x D, mm)
600 x 2,000 x 650
- Weight (kg)
390
RESU Prime Copy Link
RESU10H Prime
Specification- Usable Energy (kWh)
9.6
- Weight (kg)
111
- Dimensions (mm)
504 x 817 x 295
- Communication Interface
RS485 & CAN
- Enclosure Protection Rating
IP55
RESU Prime Copy Link
RESU16H Prime
Specification- Usable Energy (kWh)
16.0
- Weight (kg)
159
- Dimension (mm)
504 x 1086 x 295
- Communication
RS485 & CAN
- Enclosure Protection Rating
IP55
Long Duration & Energy Copy Link
R1000 (17 Packs) / M48145P5B
Specification- Energy (kWh)
126.6
- Capacity (Ah)
145
- Nominal Voltage (V)
873
- Voltage Range (V)
714 ~ 1,000
- Dimension (W x H x D, mm)
520 x 2,200 x 655
- Weight (kg)
905
Telecom Backup Solution / Residential Pack Copy Link
M48126P3S
Specification- Energy (kWh)
6.5
- Capacity (Ah)
126
- Nominal Voltage (V)
51.8
- Voltage Range (V)
42.0 ~ 58.8
- Dimension (W x H x D, mm)
445 x 110 x 587
- Weight (kg)
44
RESU Gen2 48V Copy Link
RESU12
Specification- Total Energy (kWh)
13.1
- Usable Energy (kWh)
11.7
- Weight (kg)
99.0
- Dimensions (mm)
452 x 626 x 227
- Communication Interface
CAN2.0B
- Enclosure Protection Rating
IP55
RESU Gen2 48V Copy Link
RESU10
Specification- Total Energy (kWh)
9.8
- Usable Energy (kWh)
8.8
- Weight (kg)
75
- Dimensions (mm)
452 x 484 x 227
- Communication
CAN2.0B
- Enclosure Protection Rating
IP55
Long Duration & Energy Copy Link
R1000 (17 Packs) / M48218P5B
Specification- Energy (kWh)
189.9
- Capacity (Ah)
218
- Nominal Voltage (V)
873
- Voltage Range (V)
714 ~ 1,000
- Dimension (W x H x D, mm)
520 x 2,200 x 950
- Weight (kg)
1,305
Telecom Backup Solution / Residential Pack Copy Link
M4863P3S
Specification- Energy (kWh)
3.3
- Capacity (Ah)
63
- Nominal Voltage (V)
51.8
- Voltage Range (V)
42.0 ~ 58.8
- Dimension (W x H x D, mm)
445 x 110 x 339
- Weight (kg)
24
RESU Gen2 48V Copy Link
RESU6.5
Specification- Total Energy (kWh)
6.5
- Usable Energy (kWh)
5.9
- Weight (kg)
52
- Dimensions (mm)
452 x 656 x 120
- Communication
CAN2.0B
- Enclosure Protection Rating
IP55
Long Duration & Energy Copy Link
R1000 (17 Packs) / M48290P5B
Specification- Energy (kWh)
253.2
- Capacity (Ah)
290
- Nominal Voltage (V)
873
- Voltage Range (V)
714 ~ 1,000
- Dimension (W x H x D, mm)
520 x 2,200 x 1,200
- Weight (kg)
1,680
Long Duration & Energy Copy Link
R1500 (24 Packs) / M48290P5B
Specification- Energy (kWh)
357.5
- Capacity (Ah)
290
- Nominal Voltage (V)
1,233
- Voltage Range (V)
1,008 ~ 1,411
- Dimension (W x H x D, mm)
520 x 3,150 x 1,200
- Weight (kg)
2,407
Long Duration & Energy Copy Link
TR1300
Specification- Energy (kWh)
327.712
- Capacity (Ah)
290
- Nominal Voltage (V)
1,130.36
- Voltage Range (V)
924 – 1,293.6
- Dimension (W x H x D, mm)
1040 x 1200 x 1745
- Weight (kg)
2308
Short Duration & Power Copy Link
R1000 (17 Packs) / M4864P6B
Specification- Energy (kWh)
56
- Capacity (Ah)
64
- Nominal Voltage (V)
876
- Voltage Range (V)
714 ~ 1,000
- Dimension (W x H x D, mm)
520 x 2,200 x 425
- Weight (kg)
584
Short Duration & Power Copy Link
R1000 (17 Packs) / M48128P6B
Specification- Energy (kWh)
112.1
- Capacity (Ah)
128
- Nominal Voltage (V)
876
- Voltage Range (V)
714 ~ 1,000
- Dimension (W x H x D, mm)
520 x 2,200 x 655
- Weight (kg)
924
UPS Backup Solution Copy Link
UPS Rack/10 Packs/M48128P6B
Specification- Energy (kWh)
65.9
- Continuous Power (kW)
132
- Nominal Voltage (V)
515
- Voltage Range (V)
420 ~ 588
- Dimension (W x H x D, mm)
600 x 2,000 x 800
- Weight (kg)
625
RESU Gen2 48V Copy Link
RESU3.3
Specification- Total Energy (kWh)
3.3
- Usable Energy (kWh)
2.9
- Weight (kg)
31.0
- Dimensions (mm)
452 x 403 x 120
- Communication
CAN2.0B
- Enclosure Protection Rating
IP55
RESU Gen2 48V Copy Link
RESU13
Specification- Total Energy (kWh)
13.1
- Usable Energy (kWh)
12.4
- Weight (kg)
99.0
- Dimensions (mm)
452 x 626 x 227
- Communication
CAN2.0B
- Enclosure Protection Rating
IP55
RESU Gen2 400V Copy Link
RESU7H(Type-R)
Specification- Total Energy (kWh)
7.0
- Usable Energy (kWh)
6.6
- Weight (kg)
75.0
- Dimensions (mm)
744 x 692 x 206
- Communication
RS485
- Enclosure Protection Rating
IP55
RESU Gen2 400V Copy Link
RESU7H(Type-C)
Specification- Total Energy (kWh)
7.0
- Usable Energy (kWh)
6.6
- Weight (kg)
87.0
- Dimensions (mm)
744 x 907 x 206
- Communication
CAN2.0B
- Enclosure Protection Rating
IP55
RESU Gen2 400V Copy Link
RESU10H(Type-R)
Specification- Total Energy (kWh)
9.8
- Usable Energy (kWh)
9.3
- Weight (kg)
97
- Dimensions (mm)
744 x 907 x 206
- Communication
RS485
- Enclosure Protection Rating
IP55
RESU Gen2 400V Copy Link
RESU10H(Type-C)
Specification- Total Energy (kWh)
9.8
- Usable Energy (kWh)
9.3
- Weight (kg)
99.8
- Dimensions (mm)
744 x 907 x 206
- Communication
CAN2.0B
- Enclosure Protection Rating
IP55
RESU Gen1 Copy Link
RESU6.4EX Main Pack
Specification- Total Energy (kWh)
6.4
- Weight (kg)
60.0
- Dimensions (mm)
406 x 664 x 165
- Communication
CAN, CAN open
- Enclosure Protection Rating
IP21
