Be Prepared with LG Home Battery RESU at Times Square

04.13.2020

Our Be Prepared campaign was featured on the Thomson Reuters Billboard at Times Square, NYC in April, 2020


Energy Module/Rack

M48218P5B (3P)

Specification
  • Energy (kWh)

    11.2

  • Capacity (Ah)

    218

  • Nominal Voltage (V)

    51.4

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimensions (W x H x D,inch)

    17.5 x 4.3 x 36.0

  • Weight (lbs)

    149.9

UPS Module/Rack

UPS Rack/10 Modules/M48128P6B

Specification
  • Energy (kWh)

    65.9

  • Continuous Power (kW)

    132

  • Nominal Voltage (V)

    515

  • Voltage Range (V)

    420 ~ 588

  • Dimensions (W x H x D,inch)

    23.6 x 78.7 x 31.5

  • Weight (lbs)

    1377.9

UPS Module/Rack

UPS Rack/10 Modules/M4864P6B

Specification
  • Energy (kWh)

    33.0

  • Continuous Power (kW)

    115

  • Nominal Voltage (V)

    515

  • Voltage Range (V)

    420 ~ 588

  • Dimensions (W x H x D,inch)

    23.6 x 78.7 x 25.6

  • Weight (lbs)

    859.8

UPS Module/Rack

UPS Rack/12 Modules (6S2P)/M7830P7B

Specification
  • Energy (kWh)

    28

  • Continuous Power (kW)

    250

  • Nominal Voltage (V)

    466

  • Voltage Range (V)

    397 ~ 523

  • Dimensions (W x H x D,inch)

    20.5 x 90.2 x 19.7

  • Weight (lbs)

    1058.2

Stand-alone Module/Telecom Backup

M48126P3S

Specification
  • Energy (kWh)

    6.5

  • Capacity (Ah)

    126

  • Nominal Voltage (V)

    51.8

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimensions (W x H x D,inch)

    17.5 x 4.3 x 23.1

  • Weight (lbs)

    97

Stand-alone Module/Telecom Backup

M4863P3S

Specification
  • Energy (kWh)

    3.3

  • Capacity (Ah)

    63

  • Nominal Voltage (V)

    51.8

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimensions (W x H x D,inch)

    17.5 x 4.3 x 13.3

  • Weight (lbs)

    52.9

RESU Gen2 400V

RESU10H(Type-R)

Specification
  • Total Energy (kWh)

    9.8

  • Usable Energy (kWh)

    9.3

  • Weight (lbs)

    213.8

  • Dimensions (W x H x D,inch)

    29.3 x 35.7 x 8.1

  • Communication

    RS485

  • Enclosure Protection Rating

    IP55

Compatible Inverters

RESU Gen2 400V

RESU10H(Type-C)

Specification
  • Total Energy (kWh)

    9.8

  • Usable Energy (kWh)

    9.3

  • Weight (lbs)

    220.0

  • Dimensions (W x H x D,inch)

    29.3 x 35.7 x 8.1

  • Communication

    CAN2.0B

  • Enclosure Protection Rating

    IP55

Compatible Inverters

RESU Gen2 400V

RESU10H(Type-R) Secondary Pack

Specification
  • Total Energy (kWh)

    9.8

  • Usable Energy (kWh)

    9.3

  • Weight (lbs)

    213.8

  • Dimensions (W x H x D,inch)

    29.3 x 35.7 x 8.1

  • Communication

    RS485

  • Enclosure Protection Rating

    IP55

Compatible Inverters

Power Module/Rack

R1000 (17 Modules) / M48128P6B

Specification
  • Energy (kWh)

    112.1

  • Capacity (Ah)

    128

  • Nominal Voltage (V)

    876

  • Voltage Range (V)

    714 ~ 1,000

  • Dimensions (W x H x D,inch)

    20.5 x 86.6 x 25.8

  • Weight (lbs)

    2037.1

Power Module/Rack

R1000 (17 Modules) / M4864P6B

Specification
  • Energy (kWh)

    56

  • Capacity (Ah)

    64

  • Nominal Voltage (V)

    876

  • Voltage Range (V)

    714 ~ 1,000

  • Dimensions (W x H x D,inch)

    20.5 x 86.6 x 16.7

  • Weight (lbs)

    1287.5

Power Module/Rack

R800 (14 Modules) / M48128P6B

Specification
  • Energy (kWh)

    92.3

  • Capacity (Ah)

    128

  • Nominal Voltage (V)

    721

  • Voltage Range (V)

    588 ~ 823

  • Dimensions (W x H x D,inch)

    20.5 x 74.0 x 25.8

  • Weight (lbs)

    1708.6

Power Module/Rack

R800 (14 Modules) / M4864P6B

Specification
  • Energy (kWh)

    46.2

  • Capacity (Ah)

    64

  • Nominal Voltage (V)

    721

  • Voltage Range (V)

    588 ~ 823

  • Dimensions (W x H x D,inch)

    20.5 x 74.0 x 16.7

  • Weight (lbs)

    1082.5

Power Module/Rack

M48128P6B (2P)

Specification
  • Energy (kWh)

    6.6

  • Capacity (Ah)

    128

  • Nominal Voltage (V)

    51.5

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimensions (W x H x D,inch)

    17.5 x 4.3 x 24.4

  • Weight (lbs)

    103.6

Power Module/Rack

M4864P6B (1P)

Specification
  • Energy (kWh)

    3.3

  • Capacity (Ah)

    64

  • Nominal Voltage (V)

    51.5

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimensions (W x H x D,inch)

    17.5 x 4.3 x 13.5

  • Weight (lbs)

    61.7

Energy Module/Rack

M48252P3B(4P)

Specification
  • Energy (kWh)

    13

  • Capacity (Ah)

    252

  • Nominal Voltage (V)

    51.8

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimensions (W x H x D,inch)

    17.5 x 4.3 x 45.7

  • Weight (lbs)

    196.2

Energy Module/Rack

M48126P3B(2P)

Specification
  • Energy (kWh)

    6.5

  • Capacity (Ah)

    126

  • Nominal Voltage (V)

    51.8

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimensions (W x H x D,inch)

    17.5 x 4.3 x 24.4

  • Weight (lbs)

    101.4

Energy Module/Rack

M48145P5B (2P)

Specification
  • Energy (kWh)

    7.4

  • Capacity (Ah)

    145

  • Nominal Voltage (V)

    51.4

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimensions (W x H x D,inch)

    17.5 x 4.3 x 24.4

  • Weight (lbs)

    101.4

Energy Module/Rack

M48290P5B (4P)

Specification
  • Energy (kWh)

    14.9

  • Capacity (Ah)

    290

  • Nominal Voltage (V)

    51.4

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimensions (W x H x D,inch)

    17.5 x 4.3 x 45.7

  • Weight (lbs)

    196.2

Energy Module/Rack

M48189P3B(3P)

Specification
  • Energy (kWh)

    9.8

  • Capacity (Ah)

    189

  • Nominal Voltage (V)

    51.8

  • Voltage Range (V)

    42.0 ~ 58.8

  • Dimensions (W x H x D,inch)

    17.5 x 4.3 x 36.0

  • Weight (lbs)

    149.9

Energy Module/Rack

R1000 (17 Modules) / M48290P5B

Specification
  • Energy (kWh)

    253.2

  • Capacity (Ah)

    290

  • Nominal Voltage (V)

    873

  • Voltage Range (V)

    714 ~ 1,000

  • Dimensions (W x H x D,inch)

    20.5 x 86.6 x 47.2

  • Weight (lbs)

    3703.8

Energy Module/Rack

R1000 (17 Modules) / M48252P3B

Specification
  • Energy (kWh)

    221.8

  • Capacity (Ah)

    252

  • Nominal Voltage (V)

    881

  • Voltage Range (V)

    714 ~ 1,000

  • Dimensions (W x H x D,inch)

    20.5 x 86.6 x 47.2

  • Weight (lbs)

    3719.2

Energy Module/Rack

R1000 (17 Modules) / M48189P3B

Specification
  • Energy (kWh)

    166.4

  • Capacity (Ah)

    189

  • Nominal Voltage (V)

    881

  • Voltage Range (V)

    714 ~ 1,000

  • Dimensions (W x H x D,inch)

    20.5 x 86.6 x 37.4

  • Weight (lbs)

    2896.9

Energy Module/Rack

R1000 (17 Modules) / M48126P3B

Specification
  • Energy (kWh)

    110.9

  • Capacity (Ah)

    126

  • Nominal Voltage (V)

    881

  • Voltage Range (V)

    714 ~ 1,000

  • Dimensions (W x H x D,inch)

    20.5 x 86.6 x 25.8

  • Weight (lbs)

    2010.6

Energy Module/Rack

R1000 (17 Modules) / M48218P5B

Specification
  • Energy (kWh)

    189.9

  • Capacity (Ah)

    218

  • Nominal Voltage (V)

    873

  • Voltage Range (V)

    714 ~ 1,000

  • Dimensions (W x H x D,inch)

    20.5 x 86.6 x 37.4

  • Weight (lbs)

    2877.0

Energy Module/Rack

R1000 (17 Modules) / M48145P5B

Specification
  • Energy (kWh)

    126.6

  • Capacity (Ah)

    145

  • Nominal Voltage (V)

    873

  • Voltage Range (V)

    714 ~ 1,000

  • Dimensions (W x H x D,inch)

    20.5 x 86.6 x 25.8

  • Weight (lbs)

    1995.2

Energy Module/Rack

R800 (14 Modules) / M48218P5B

Specification
  • Energy (kWh)

    156.4

  • Capacity (Ah)

    218

  • Nominal Voltage (V)

    719

  • Voltage Range (V)

    588 ~ 823

  • Dimensions (W x H x D,inch)

    20.5 x 74.0 x 37.4

  • Weight (lbs)

    2418.5

Energy Module/Rack

R800 (14 Modules) / M48252P3B

Specification
  • Energy (kWh)

    182.7

  • Capacity (Ah)

    252

  • Nominal Voltage (V)

    725

  • Voltage Range (V)

    588 ~ 823

  • Dimensions (W x H x D,inch)

    20.5 x 74.0 x 47.2

  • Weight (lbs)

    3090.8

Energy Module/Rack

R800 (14 Modules) / M48189P3B

Specification
  • Energy (kWh)

    137

  • Capacity (Ah)

    189

  • Nominal Voltage (V)

    725

  • Voltage Range (V)

    588 ~ 823

  • Dimensions (W x H x D,inch)

    20.5 x 74.0 x 37.4

  • Weight (lbs)

    2433.9

Energy Module/Rack

R800 (14 Modules) / M48126P3B

Specification
  • Energy (kWh)

    91.3

  • Capacity (Ah)

    126

  • Nominal Voltage (V)

    725

  • Voltage Range (V)

    588 ~ 823

  • Dimensions (W x H x D,inch)

    20.5 x 74.0 x 25.8

  • Weight (lbs)

    1688.7

Energy Module/Rack

R800 (14 Modules) / M48290P5B

Specification
  • Energy (kWh)

    208.5

  • Capacity (Ah)

    290

  • Nominal Voltage (V)

    719

  • Voltage Range (V)

    588 ~ 823

  • Dimensions (W x H x D,inch)

    20.5 x 74.0 x 47.2

  • Weight (lbs)

    3077.6

Energy Module/Rack

R800 (14 Modules) / M48145P5B

Specification
  • Energy (kWh)

    104.3

  • Capacity (Ah)

    145

  • Nominal Voltage (V)

    719

  • Voltage Range (V)

    588 ~ 823

  • Dimensions (W x H x D,inch)

    20.5 x 74.0 x 25.8

  • Weight (lbs)

    1675.5

Energy Module/Rack

R1500 (24 Modules) / M48290P5B

Specification
  • Energy (kWh)

    357.5

  • Capacity (Ah)

    290

  • Nominal Voltage (V)

    1,233

  • Voltage Range (V)

    1,008 ~ 1,411

  • Dimensions (W x H x D,inch)

    20.5 x 124.0 x 47.2

  • Weight (lbs)

    5306.5
