RESU Plus Copy Link

RESU Plus

Specification

Home Battery Package Copy Link

LGES Inverter & LV Battery (RESU6.5/RESU10/RESU12)

Specification

Gen2 48V Copy Link

RESU12

Specification

Prime Copy Link

16H Prime

Specification

Compatible Inverters

Prime Copy Link

10H Prime

Specification

• Usable Energy (kWh)

  9.6

• Weight (kg)

  111

• Dimensions (mm)

  504 x 817 x 295

• Communication Interface

  CAN & RS485

• Enclosure Protection Rating

  IP55

Compatible Inverters

Long Duration & Energy Copy Link

R1000 (17 Packs) / M48145P5B

Specification

• Energy (kWh)

  126.6

• Capacity (Ah)

  145

• Nominal Voltage (V)

  873

• Voltage Range (V)

  714 ~ 1,000

• Dimension (W x H x D, mm)

  520 x 2,200 x 655

• Weight (kg)

  905

Long Duration & Energy Copy Link

R1000 (17 Packs) / M48218P5B

Specification

• Energy (kWh)

  189.9

• Capacity (Ah)

  218

• Nominal Voltage (V)

  873

• Voltage Range (V)

  714 ~ 1,000

• Dimension (W x H x D, mm)

  520 x 2,200 x 950

• Weight (kg)

  1,305

Long Duration & Energy Copy Link

R1000 (17 Packs) / M48290P5B

Specification

• Energy (kWh)

  253.2

• Capacity (Ah)

  290

• Nominal Voltage (V)

  873

• Voltage Range (V)

  714 ~ 1,000

• Dimension (W x H x D, mm)

  520 x 2,200 x 1,200

• Weight (kg)

  1,680

Long Duration & Energy Copy Link

R1500 (24 Packs) / M48290P5B

Specification

• Energy (kWh)

  357.5

• Capacity (Ah)

  290

• Nominal Voltage (V)

  1,233

• Voltage Range (V)

  1,008 ~ 1,411

• Dimension (W x H x D, mm)

  520 x 3,150 x 1,200

• Weight (kg)

  2,407

Long Duration & Energy Copy Link

TR1300

Specification

• Energy (kWh)

  327.712

• Capacity (Ah)

  290

• Nominal Voltage (V)

  1,130.36

• Voltage Range (V)

  924 – 1,293.6

• Dimension(WxHxD, mm)

  1040 x 1200 x 1745

• Weight (kg)

  2308

Gen2 48V Copy Link

RESU6.5

Specification

• Total Energy (kWh)

  6.5

• Usable Energy (kWh)

  5.9

• Weight (kg)

  52.0

• Dimensions (mm)

  452 x 656 x 120

• Communication

  CAN2.0B

• Enclosure Protection Rating

  IP55

Compatible Inverters

Short Duration & Power Copy Link

R1000 (17 Packs) / M4864P6B

Specification

• Energy (kWh)

  56

• Capacity (Ah)

  64

• Nominal Voltage (V)

  876

• Voltage Range (V)

  714 ~ 1,000

• Dimension (W x H x D, mm)

  520 x 2,200 x 425

• Weight (kg)

  584

Short Duration & Power Copy Link

R1000 (17 Packs) / M48128P6B

Specification

• Energy (kWh)

  112.1

• Capacity (Ah)

  128

• Nominal Voltage (V)

  876

• Voltage Range (V)

  714 ~ 1,000

• Dimension (W x H x D, mm)

  520 x 2,200 x 655

• Weight (kg)

  924

Gen2 48V Copy Link

RESU10

Specification

• Total Energy (kWh)

  9.8

• Usable Energy (kWh)

  8.8

• Weight (kg)

  75.0

• Dimensions (mm)

  452 x 484 x 227

• Communication

  CAN2.0B

• Enclosure Protection Rating

  IP55

Compatible Inverters

Gen2 48V Copy Link

RESU13 (Superseded)

Specification

• Total Energy (kWh)

  13.1

• Usable Energy (kWh)

  12.4

• Weight (kg)

  99.0

• Dimensions (mm)

  452 x 626 x 227

• Communication

  CAN2.0B

• Enclosure Protection Rating

  IP55

Compatible Inverters

UPS Backup Solution Copy Link

UPS Rack/10 Packs/M4864P6B

Specification

• Energy (kWh)

  33.0

• Continuous Power (kW)

  115

• Nominal Voltage (V)

  515

• Voltage Range (V)

  420 ~ 588

• Dimension (W x H x D, mm)

  600 x 2,000 x 650

• Weight (kg)

  390

Telecom Backup Solution / Residential Pack Copy Link

M4863P3S

Specification

• Energy (kWh)

  3.3

• Capacity (Ah)

  63

• Nominal Voltage (V)

  51.8

• Voltage Range (V)

  42.0 ~ 58.8

• Dimension (W x H x D, mm)

  445 x 110 x 339

• Weight (kg)

  24

Telecom Backup Solution / Residential Pack Copy Link

M48126P3S

Specification

• Energy (kWh)

  6.5

• Capacity (Ah)

  126

• Nominal Voltage (V)

  51.8

• Voltage Range (V)

  42.0 ~ 58.8

• Dimension (W x H x D, mm)

  445 x 110 x 587

• Weight (kg)

  44

UPS Backup Solution Copy Link

UPS Rack/10 Packs/M48128P6B

Specification

• Energy (kWh)

  65.9

• Continuous Power (kW)

  132

• Nominal Voltage (V)

  515

• Voltage Range (V)

  420 ~ 588

• Dimension (W x H x D, mm)

  600 x 2,000 x 800

• Weight (kg)

  625
